As per the below mentioned specifications our products are manufactured for various applications like Agriculture, Cattle Pen Tubes, Chilled Water Systems, Construction Tubes, Conveyor Roller Tubes, Fence Tubes, Fire Fighting Applications, Gas & Water Tubes, Green House Tubes, Handrails, Hollow Sections Structural tubes, Lighting poles, Mechanical & General Engineering, Parking Posts, Scaffolding, Space frames, Sprinkler systems, Submersible / Deep Water & Casing pipes, Telecommunication poles, Tubular Poles etc.
| STANDARD SIZE SPECIFICATION FOR (HOLLOW SECTIONS IN SQUARE & RECTANGULAR SHAPES) | |
|---|---|
| SIZE OF SQUARE SHAPES | |
| Size Range(Min-MAX) | Wall Thickness |
| 19x19 mm - 100x100 mm | 1.4 mm to 4.5 mm |
| SIZE OF RECTANGULAR SHAPES | |
| Size Range(Min-MAX) | Wall Thickness |
| 10x30 mm - 50x100 mm | 1.4 mm to 4.5 mm |
| Nominal Size of Conduit (in mm) | Outside Diameter(in mm) | Tolerance in outside Diameter (in mm) | Wall thickness of Conduit (Range in mm) |
|---|---|---|---|
| 20 | 20 | 0-0.3 | 1.4 to 1.8 |
| 25 | 25 | 0-0.4 | 1.4 to 1.8 |
| 32 | 32 | 0-0.4 | 1.4 to 1.8 |
| 40 | 40 | 0-0.4 | 1.6 to 2.2 |
| 50 | 50 | 0-0.5 | 1.6 to 2.2 |
Length:4m, Min Length:3m
